EAD 280001-00-0704預制排水或過濾管線單元歐盟ETA認證
發布日期：2025-3-18 9:29:40 閱讀次數：152
預制排水或過濾管線單元歐盟ETA認證－EAD 280001-00-0704適用范圍
EAD 280001-00-0704 Preassembled line unit used for drainage of infiltration 預制排水或過濾管線單元
Preassembled line unit used for drainage or infiltration. Two possibilities are presented:
The preassembled linear unit comprises a horizontal corrugated slotted or perforated pipe
of polyethylene, EPS aggregates that are held surrounding the pipe by means of a
netting and a geotextile which covers at least the upper two thirds of the outer surface.
The units are set end to end by plastic couplers.
The preassembled linear unit comprises EPS aggregates that are held by means of a
netting and a geotextile which covers at least the upper two thirds of the outer surface.
The units are not set end to end.
In both cases the unit length varies between 2 and 12 m. The outer diameter of the plastic
pipes is in the range between 70 and 200 mm. The outer diameter of the preassembled lineunit is in the range between 225 and 450 mm. An example of dimensions of the EPS
aggregate is included in the annex B.
The following table shows the possible product combinations in accordance with the product parameters and intended use possibilities.
預制排水或過濾管線單元出口歐盟，需滿足ETA認證要求，主要測試包括：
1. 防火等級 Reaction to fire (EN 13501-1)
2. 危險物質的含量、排放和/或釋放
3. 載荷下的變形
4. 負載下的水流能力
5. 聚乙烯管的環剛度
6. 土工織物的靜態穿刺(CBR測試)
7. 土工織物的動態穿孔試驗(錐形落錘試驗）
8. EPS聚合物的壓縮模量
9. 壓縮蠕變
10. 氧化老化后的負載變形
11. 水解老化后的負載下變形
12. 微生物老化后的載荷變形
13. 土工織物的耐風化性
14. 土工織物的抗氧化性
預制排水或過濾管線單元歐盟ETA認證－認證體系
System 1 或者 System 3
ETA認證與CPR指令CE認證的關系
Under the CPR, harmonised technical specifications are harmonised European product standards (hENs) established by CEN/CENELEC2 or European Assessment Documents (EADs) produced by the European
CPR指令認證的依據是建筑指令歐盟協調標準或歐盟評估文件（EADs）
European Organisation for Technical Approvals (EOTA) as the basis for issuing ETAs for products not covered by hENs.The harmonised technical specification for a product defines EEA-wide methods of assessing and declaring
對于沒有被協調標準完全覆蓋的建筑產品的認證，可以通過EOTA機構核發ETA認證證書（等同于CE認證書）。
南京睿督授權合作實驗室同時為歐盟NB及TAB機構，可以同時受理建材歐盟CE認證和歐盟ETA認證。南京睿督為客戶提供專業合規的歐盟CE認證和ETA認證，減少認證中間溝通環節，權威省時省力。
南京睿督公司咨詢電話：025-86583475 400-603-6575
網址：www.shseg-gps.com www.cprce.com
郵箱：info@hksmartps.com
微信：firetesting 或 17714189018
……
